Time for some geeking out. I’m one of those fools who like to run their own local server with not cloud shenanigans. I’ve been running an Ubuntu server for a while with a bunch of individually installed services, but I wanted to try something more compartmentalized, easier to maintain and update. The obvious choice would have been Docker, but I like to make my life complicated so I installed Fedora with the plan of using Podman with Quadlet.
This post is mostly a note-to-self so I have some documentation of the process next time I need to reinstall everything.
I assume you already have Fedora (44 in my case) and podman installed. The first thing to do is to create the *.containers directory in your home for quadlet to use:
mkdir -p ~/.config/containers/systemd
nzbget, radarr and sonarr all need to talk in the same network, so we need to create a custom network for them. This is something I haven’t seen mentioned in other tutorials, but without this step I wasn’t able to get them to communicate properly.
In the directory we just created, add a file called ~/.config/containers/systemd/arr.network with the following content:
[Network]
NetworkName=arr_net
Next we need the volumes for the containers. I have a big storage drive mounted at /mnt/storage where I keep all my media and related files, so I created the following directories:
mkdir -p /mnt/storage/media/{nzbget,radarr,sonarr,downloads,Movies,TV}
Remember that we are creating a rootless setup, so we need to make sure that the user running the containers is the same as the owner of the files and directories; in my case is matteo.
NZBGet
Now we start configuring the actual containers. First NZBGet. Create a file called ~/.config/containers/systemd/nzbget.service with the following content:
[Unit]
Description=NZBGet
After=network-online.target
[Container]
Image=ghcr.io/nzbgetcom/nzbget:latest
ContainerName=nzbget
# Environment variables
Environment=PUID=0
Environment=PGID=0
Environment=TZ=Europe/Rome
# Ports and Volumes
Network=arr.network
PublishPort=6789:6789
Volume=/mnt/storage/media/nzbget:/config:Z
Volume=/mnt/storage/media/downloads:/downloads:z
# This enables automatic updates
AutoUpdate=registry
[Service]
Restart=always
TimeoutStartSec=900
[Install]
WantedBy=default.target
The file is pretty basic, the only thing to note is that we are using the custom network we created before (Network=arr.network)and that we are mounting the volumes with :Z and :z options to make sure SELinux doesn’t get in the way. It’s important to note the difference between uppercase and lowercase Z here, the former will allow only the container to access the volume, while the latter will allow other processes on the host to access it as well. Of course we want the downloads volume to be accessible from radarr and sonarr, so we use :z (lowercase) for that one.
Also note that we are setting PUID and PGID to 0. In a perfect world we would want to set these to the actual user and group IDs (eg: 1000), and then use podman unshare chown to change the ownership of the directory /mnt/storage/media. That totally works but doing so I can’t access the files and directories directly from the host without using sudo. Setting PUID and PGID to 0 might not be ideal but it seems to work. Let me know if you have a better solution for this. Remember that setting them to 0 in a non-root environment doesn’t give the container root privileges, so it shouldn’t be a security issue.
Let’s give nzbget a try before moving on to the other containers. Run the following command to start it:
systemctl --user daemon-reload
systemctl --user start nzbget
If everything went well you should be able to access the nzbget web interface at http://[server-ip]:6789 and log in with the default credentials (admin:tegbzn6789). At this point you should ensure that nzbget is using the correct paths, and of course you’ll need a news server.
Under settings > security make sure to set ControlIP to 0.0.0.0, and resolve any other issues outlined in the messages section.
Lingering
We also want to start nzbget automatically on boot. By default, rootless systemd --user sessions only start when a user logs in and tear down upon logout. To force the system to initialize your specific user session at boot, we need “lingering” enabled. Run this command with administrative privileges:
sudo loginctl enable-linger $USER
Radarr and Sonarr
Okay, time to move on to radarr. Create a file called ~/.config/containers/systemd/radarr.service with the following content:
[Unit]
Description=Radarr
After=network-online.target
[Container]
Image=lscr.io/linuxserver/radarr:latest
ContainerName=radarr
Environment=PUID=0
Environment=PGID=0
Environment=TZ=Europe/Rome
Network=arr.network
PublishPort=7878:7878
Volume=/mnt/storage/media/radarr:/config:Z
Volume=/mnt/storage/media/downloads:/downloads:z
Volume=/mnt/storage/media/Movies:/movies:z
AutoUpdate=registry
[Service]
Restart=always
TimeoutStartSec=900
[Install]
WantedBy=default.target
The configuration is pretty much the same as nzbget, we just need to change the image, the container name, the ports and the volumes. The important thing is that we are using the same custom network (Network=arr.network) so that radarr can talk to nzbget. Same as before note the use of :Z and :z for the volumes.
And finally sonarr. Create a file called ~/.config/containers/systemd/sonarr.service with the following content:
[Unit]
Description=Sonarr
After=network-online.target
[Container]
Image=ghcr.io/linuxserver/sonarr:latest
ContainerName=sonarr
Environment=PUID=0
Environment=PGID=0
Environment=TZ=Europe/Rome
Network=arr.network
PublishPort=8989:8989
Volume=/mnt/storage/media/sonarr:/config:Z
Volume=/mnt/storage/media/downloads:/downloads:z
Volume=/mnt/storage/media/TV:/tv:z
AutoUpdate=registry
[Service]
Restart=always
TimeoutStartSec=900
[Install]
WantedBy=default.target
We can now start both radarr and sonarr with the same commands we used for nzbget:
systemctl --user daemon-reload
systemctl --user start radarr
systemctl --user start sonarr
If everything went well you should be able to access the web interfaces at http://[server-ip]:7878 for radarr and http://[server-ip]:8989 for sonarr. You can then configure them to use the correct paths, and of course set up the indexers and the connection to nzbget.
When creating a new Download Client in radarr and sonarr, make sure to use the actual IP address of the server (eg: 192.168.1.2). localhost or 127.0.0.1 won’t work.
Congratulations, you now have nzbget, radarr and sonarr running in rootless podman containers that start on boot. To have it also update automatically we need one more step.
Automatic Updates
Thanks to the AutoUpdate=registry, all containers are already configured to update automatically when a new image is available on the registry, but we need to enable the podman-auto-update.timer systemd timer to make it work considering my server is always on.
Run the following command:
systemctl --user enable --now podman-auto-update.timer
That’s it, now your containers will be automatically updated when a new image is available. You can check the status of the timer with:
systemctl --user status podman-auto-update.timer
It’s not technically recommended to have automatic updates, basically if it works, don’t touch it. But I like to live on the edge and I can always roll back to a previous image if something breaks.
Bonus: Reverse Proxy with nginx
Everything seems to be working, but I want to access the services with nice URLs like http://nzbget.cool.domain instead of http://192.168.1.2:6789. To do that I set up a reverse proxy with nginx. It’s pretty straightforward, but –again– SELinux can be a bit of a pain.
I’m already running a full authoritative DNS server with unbound so it’s easy for me to redirect custom domains to my server IP, but you can achieve the same result in multiple ways (like editing your hosts file or using a different DNS server or even PI-Hole).
For unbound I added the following lines to my configuration:
...
local-zone: "cool.domain." static
local-data: "nzbget.cool.domain. IN A 192.168.1.2"
local-data: "radarr.cool.domain. IN A 192.168.1.2"
local-data: "sonarr.cool.domain. IN A 192.168.1.2"
...
local-data-ptr: "192.168.1.2 nzbget.cool.domain."
local-data-ptr: "192.168.1.2 radarr.cool.domain."
local-data-ptr: "192.168.1.2 sonarr.cool.domain."
...
Then I installed and enabled nginx with:
sudo dnf install nginx
sudo systemctl --now enable nginx
We also need to relax SELinux to allow nginx to make outbound connections. Run the following command:
sudo setsebool -P httpd_can_network_connect 1
Since we are at it I also created a self signed SSL certificate for the domain so I can access the services over HTTPS. To do that I ran the following command:
openssl req -x509 -newkey rsa:4096 -sha512 -days 3650 -noenc -keyout cool.domain.key -out cool.domain.crt -subj "/CN=cool.domain" -addext "subjectAltName=DNS:cool.domain,DNS:*.cool.domain,IP:192.168.1.2"
Of course change cool.domain (can be anything, even made up) with your actual domain and 192.168.1.2 with your server IP. That will generate a certificate valid for 10 years, copy the .crt and .key files to a sensible location (eg: /etc/nginx/certs/) and then inform SELinux about the new files with:
sudo restorecon -Rv /etc/nginx/certs
Finally we can create the nginx configuration for the reverse proxy. Create a file called proxy.conf in /etc/nginx/conf.d/ with the following content:
server {
listen 80;
server_name nzbget.cool.domain;
return 301 https://$host$request_uri;
}
server {
listen 443 ssl;
listen [::]:443 ssl;
http2 on;
server_name nzbget.cool.domain;
ssl_certificate "/etc/nginx/certs/cool.domain.crt";
ssl_certificate_key "/etc/nginx/certs/cool.domain.key";
ssl_session_cache shared:SSL:1m;
ssl_session_timeout 10m;
ssl_ciphers PROFILE=SYSTEM;
ssl_prefer_server_ciphers on;
location / {
proxy_pass http://127.0.0.1:6789;
# Pass correct headers to NZBGet
proxy_set_header Host $host;
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Forwarded-Proto $scheme;
# Allow large file uploads via the web UI if necessary
client_max_body_size 100M;
}
}
Repeat the same for radarr and sonarr, just changing the server_name and the port in proxy_pass. Reload nginx and you should be able to access the services with the nice URLs we set up.
Conclusion
I’m not sure if this is the best way to set everything up but seems to be working fine for me. I especially like that I don’t need to change the permission on the shared volumes and my main user still has read/write access to the media files. I also have an NFS partition mounted using the same user and group so everything is integrated seamlessly.
If you have any suggestions or improvements drop me a message or find me on Mastodon or Discord.
